Description
Short Version:Click Here
Realacc 5.8G 5dBi 50W Omnidirectional Flat Panel Antenna Omni Tower Plated FPV Antenna SMA/RP-SMA
Realacc 5.8G 5dBi 50W Omnidirectional Flat Panel Antenna Omni Tower Plated FPV Antenna SMA/RP-SMA
Thanks the designer Maarten baert, who gives the idea, if you want more information, pls click:http://www.maartenbaert.be/quadcopters/antennas/pagoda-antenna/
Features :
– 5dBi High Gain & Omni-Directional Radiation Delivers 360 signal coverage with no dead corners, ensuring stable FPV feed whether flying forward, backward or sidewaysideal for racing and freestyle maneuvers.- Low VSWR (<1.5:1) for Strong Anti-Interference Signal Minimizes signal attenuation and flash, maintaining clear transmission even in crowded multi-pilot flight environments or complex outdoor terrain.- 50W Max Power Handling Capacity Supports high-power FPV VTX modules without signal distortion, perfect for long-range transmission setups.- Dual Connector Compatibility (RP-SMA/SMA) Works with most mainstream FPV transmitters and receivers, eliminating adapter hassle for flexible drone builds.- Ultra-Lightweight Compact Design Weighs only 8.6g with 783mm length, adding negligible payload to preserve drone agilityy and flight efficiency.- 3 Color Options (Black/Red/White) Allows personalized customization to match your drone’s aesthetic.- 5.8GHz Full-Band Support Seamlessly fits standard FPV frequency bands, ensuring universal compatibility with 5.8G VTX/VRX systems.
Description :
| Brand Name : | Realacc |
| Item Name : | Omnidirectional Antenna |
| Gain : | 5dBi |
| Max. Power : | 50w |
| Connector : | RP-SMA,SMA |
| Color : | Black, Red, White |
| Weight : | 8.6g |
| Length : | 783mm |
| Max. Dia. : | 22.41mm |
| Min. Dia. : | 11.81mm |
Specification :
| Frequency : | 5.8GHz |
| Impedance : | 50 |
| VSWR : | <1.5:1 |
| Polarization : | Circular Polarized |
| Radiation : | Omni |
Package Included :
1 x Antenna
,
,
,
,
,
,
,
