EWRF Analog FPV Camera & 200mW FPV Transmitter, 1200TVL, 5.8GHz 48CH VTX, 120 FOV, TBS Compatible for Mini FPV Drones

Description

Feature

1. 48CH Full-Band 5.8G Compatibility Supports all 5.8GHz FPV channels seamlessly matching most FPV goggles and receivers ideal for multi-pilot flights or diverse drone setups.
2. 1200TVL Wide-Angle Imaging 1200TVL high-definition camera with 120 diagonal/100 horizontal/80 vertical perspective (F=2.4mm focal length) captures clear wide-range visuals eliminating blind spots for precise navigation.
3. 3-Speed Adjustable Power (25/100/200mW) Switch power levels to adapt to different flight scenarios 25mW for indoor use 200mW for medium-range outdoor flights balancing signal stability and power efficiency.
4. Versatile Image Adjustments Supports PAL/NTSC format switching and image flipping meeting diverse installation and regional signal requirements with no extra tools needed.
5. Ultra-Compact Lightweight Design Measures 15*17*60mm and weighs only 5g adding negligible payload to drones preserving flight agilityy especially for small or lightweight FPV models.
6. Wide Voltage Compatibility (5-24V) Works with 5V-24V power supplies fitting most RC drone battery setups (e.g., 2S-6S) with stable current performance (170-250mA at 12V) ensuring reliable operation.
7. Standard IPEX 1 Interface Universal IPEX 1 antenna connector enables easy pairing with most FPV antennas supporting quick replacement or upgrade without adapter hassle.



Description:

Model:	5.8G 48CH 200mW Transmitter Camera
Camera:	1200TVL Wide angle camera
Perspective:	Diagonal 120, Horizontal 100, Vertical 80
Focal length:	F=2.4mm
Antenna interface :	IPEX 1
Size:	15*17*60mm
Weight:	About 5g
	PAL/NTSC adjust
Image flipping:	supported
Voltage:	5-24V
Frequency method:	Buttom
Power:	25mW/100mW/200mW adjusted
12V Current:	170mA(25mW)/210mA(100mW)/250mA(200mW)

Package Included:

1X 5.8G 48CH 200mW Transmitter Camera
